机器型号Machine Model |
SC-3 |
SC-4 |
|
外形尺寸Overall Dimension |
L 810 *W1260 * H 1575 |
|
控制方式Control Method |
工控机+运动控制板卡IPC+motion control card |
|
涂覆区域（XYZ）Coating Area |
X=450mm Y=450mm Z=100mm |
|
X、Y、Z 驱动方式Driven Method |
伺服马达+滚珠丝杆Servo Motor+ball screw |
|
U轴驱动方式U axis Driven Method |
无N/A |
伺服电机+同步带Servo motor+synchronous belt |
|
调幅方式width method |
电动electric |
|
最高运行速度Max. Running Speed |
600mm/S |
|
定位精度Positioning Accuracy |
±0.03 |
|
重复定位精度Repeat Positioning Accuracy |
±0.02 |
|
搭载胶阀Nozzle Matched |
撞针式点胶阀+锥形小雾花 （胶阀可倾斜35度）Firing pin nozzle + cone nozzle (nozzle tilt at 35 degree) |
|
元件最大高度Max. Height (component) |
上up 下down 100mm |
|
涂料容量glue capacity |
10L , 20L , 40L |
|
通讯接口Communication port |
SMEMA |
|
扫描仪插口scanning port |
232接口 |
|
编程模式programming mode |
文件导入或手动示教file imported or manual teaching |
|
输入电压voltage input |
220V 50-60HZ |
|
输入气压air input |
4KG |
|
总功率total power |
3KW |
|
总重量total weight |
500KG |
|
自动清洗装置automatic clean system |
标配standard |
|
CCD |
选配optional |
|
条码扫描bar code scanner |
选配optional |
|
扇形大雾花胶阀sector shape nozzle |
选配optional |
|
自动清洗装置automatic clean system |
选配optional |
